1/72 Italeri F4U-7 Corsair

Post by LTmodelmaking »

Hi, everyone. I'll be entering this group build with this 1/72 Italeri F4U-7. My goal is to build a Corsair that was involved in the 1956 Suez crisis.

A little bit of history:

Aéronavale:
After the war, the French Navy had an urgent requirement for a powerful carrier-born close-air support aircraft to operate from the French Navy's four aircraft carriers that it acquired in the late 1940s (Two former U.S. Navy and two Royal Navy carriers were transferred). Secondhand US Navy Douglas SBD Dauntless dive-bombers of Flotille 3F and 4F were used to attack enemy targets and support ground forces in the north of Indo-China. Former US Grumman F6F-5 Hellcats and Curtiss SB2C Helldivers replaced the Dauntless in attacking roads, bridges and providing close air support. A new and more capable aircraft was needed.

First Indochina War
The last production Corsair was the "F4U-7", which was built specifically for the French naval air arm, the Aéronavale. The XF4U-7 prototype did its test flight on 2 July 1952 with a total of 94 F4U-7s built for the French Navy's Aéronavale (79 in 1952, 15 in 1953), with the last of the batch, the final Corsair built, rolled out on 31 January 1953.[87] The F4U-7s were actually purchased by the U.S. Navy and passed on to the Aéronavale through the U.S. Military Assistance Program (MAP). The French Navy used its F4U-7s during the second half of the First Indochina War in the 1950s (12.F, 14.F, 15.F Flotillas), where they were supplemented by at least 25 ex-USMC AU-1s passed on to the French in 1954, after the end of the Korean War.

On 15 January 1953, Flotille 14F, based at Karouba Air Base near Bizerte in Tunisia, became the first Aéronavale unit to receive the F4U-7 Corsair. Flotille 14F pilots arrived at Da Nang on 17 April 1954, but without their aircraft. The next day, the carrier USS Saipan delivered 25 war-weary ground attack Ex-USMC AU-1 Corsairs (flown by VMA-212 at the end of the Korean War). During three months operating over Dien Bien Phu and Viêt-Nam, the Corsairs flew 959 combat sorties totaling 1,335 flight hours. They dropped some 700 tons of bombs and fired more than 300 rockets and 70.000 20mm rounds. Six aircraft were damaged and two shot down by Viet Minh.

In September 1954, F4U-7 Corsairs were loaded aboard the Dixmude and brought back to France in November. The surviving Ex-USMC AU-1s were taken to the Philippines and returned to the U.S. Navy. In 1956, Flotille 15F returned to South Vietnam, equipped with F4U-7 Corsairs.

Suez Crisis
The 14.F and 15.F Flotillas also took part in the Anglo-French-Israeli seizure of the Suez Canal in October 1956, code-named Operation Musketeer. The Corsairs were painted with yellow and black recognition stripes for this operation. They were tasked with destroying Egyptian Navy ships at Alexandria but the presence of U.S. Navy ships prevented the successful completion of the mission. On 3 November 16. F4U-7s attacked airfields in the Delta, with one corsair shot down by anti-aircraft fire. Two more Corsairs were damaged when landing back on the carriers. The Corsairs engaged in Operation Musketeer dropped a total of 25 tons of bombs, fired more than 500 rockets and 16.000 20mm rounds.

If you want to read up more about the Corsair: http://en.wikipedia.org/wiki/Vought_F4U_Corsair

More links that might interest you about the French Corsairs:
http://warbirdinformationexchange.org/p ... p?p=202389
http://www.ig-corsair.de/F4U-7%20Aeronavale.html

A restored Corsair flying again:
[youtube]71W4x169fzc[/youtube]

Documentary about the Suez crisis:
[youtube]ETOUALw2EIs[/youtube]


This is what I'll be using:





User avatar
LTmodelmaking
Corporal
Corporal
Posts: 68
Joined: Sun Oct 13, 2013 3:27 pm
Location: Lithuania

Re: 1/72 Italeri F4U-7 Corsair

Post by LTmodelmaking »

Some progress has been made:

When I bought the kit I didn't expect that so much scratchbuilding and detalisation will have to be made. The kit isn't that bad but comparing it to other Corsairs on the market it has some deficiencies. It lacks some details and fineness. Cockpit walls have no details, plastic is thin in places, cannon barrels are terrible representations of the real things, there are plenty of sink marks, instrument dials are a bunch of blobs, that's why I decided to replace them with a better Eduard photo-etched instrument panel(albeit it is the wrong one). Panel lines are a little too shallow so I decided to deepen them. The engine is a blob of plastic so I'll replace it with a 1/72 one from Quickboost that I was going to use on an Academy P-47D(again a wrong one because French Corsair used engines from F4U-4Bs). It's hard to find aftermarket in Lithuania, okay. :? Also I tried scratchbuilding a new seat. More tries will be required to achieve desirable results.

Photo time ;) :













User avatar
LTmodelmaking
Corporal
Corporal
Posts: 68
Joined: Sun Oct 13, 2013 3:27 pm
Location: Lithuania

Re: 1/72 Italeri F4U-7 Corsair

Post by LTmodelmaking »

More work:

I decided to make dropped landing flaps. I don't know how well it'll turn out but we'll see :?


Did some fitting to see how everything will look like



The PE instrument panel should fit fine but now I have a dilemma. Should I scratch-build the side consoles or should I use photo-etch. Again, we will see
